The Legrand Viking Separation Terminal Block is a technical device designed for secure and effective electrical interconnection. This component is ideal for use in various electrical applications. The product, being from the reputed brand Legrand Viking, ensures high quality, reliability, and longevity. The separation feature in the terminal block allows for organized and safe wire distribution, facilitating ease of use and installation.
Specifications
Connectable conductor cross section fine-strand without cable end sleeve (mm²) : 35 mm² to 120 mm²
Connectable conductor cross section fine-strand with cable end sleeve (mm²) : -35 mm² to 120 mm²
Connectable conductor cross section solid-core (mm²) : 35 mm² to 120 mm²
Connectable conductor cross section multi-wired (mm²) : 35 mm² to 120 mm²
Rated current In (A) : 340
Rated voltage (V) : 1000
Type of electrical connection 1 : Screw connection
Type of electrical connection 2 : Bolt connection
Number of levels : 1
Number of clamp positions per level : 1
Internally connected stages : No
Mounting method : DIN rail (top hat rail) 35 mm
Material insulation body : Thermoplastic
Inflammability class of insulation material according to with UL94 : V2
Operating temperature (°C) : -5 °C to 40 °C
Width (mm) : 42
Height (mm) : 89.5
Depth (mm) : 296
Closing plate required : No
Color : Grey
Type of slitting : Swivelling
With integrated test socket : Yes
