Uxcell Momentary Metal Push Button Switch Mounting Light

About this item

• Item Name: Push Button Switch; Type: Momentary; Contact Type: DPDT(2NO 2NC 1COM)
• (Rated) Voltage & Current: 250V 5A; Light Voltage: 24V; Light Color: Blue
• Mounting Hole Dia: 22mm/0.87″; Terminals Quantity: 8; Head Shape: Hex Flat Head
• Package Content: 1 x Push Button Switch; Total Size: 40 x 29mm/1.57 x 1.41″(L*Max.W)
• Used widely for Power Button Switch, Led Switch, DIY projects or any circuit controls. The housing is waterproof and can be used in wet or dusty environments.

Descriptions:

Momentary type, DPDT 2NO 2NC 1COM contact, 8 terminals.

This metal push button switch is suitable for 22mm diameter mounting hole.

Used widely: Great for Power Button Switch, Led Switch, DIY projects or any circuit controls.

Specification:

Item Name: Push Button Switch

Action Type: Momentary Type

Head Shape: Hex Flat Head

Contact: DPDT(2NO 2NC 1COM)

Switch Rating: AC 250V 5A

Switch Color: Silver Tone

Lamp Voltage: 24V

Light Color: Blue

Pin Number: 8

Thread Diameter: 22mm/0.87in

Total Size: 40 x 29mm/1.57in x 1.41in(L*Max.W)

Material: Copper Nickel Plating

Package Content:

1 x Push Button Switch
