Uxcell HK Series Needle Roller Bearings, Open End, Stamping Steel Drawn Cup, Metric

About this item

• Model: HK2012 (Bore Dia. (Fw)= 20mm, Outer Dia. (D)a= 26mm, Width (C)= 12mm)
• ST14 Steel Drawn Cup, ST13 Steel Cage, GCr15 Needle Roller
• Good heat tolerance, high load carrying capacity and stiffness
• Low cross section, enable downsizing and suit for use in restricted mounting spaces
• Pre-Lubricated. Good running properties

1.Drawn Cup Needle Roller Bearing features a deep drawn, thin-walled outer ring. They are compact bearings with high load carrying capacity and stiffness.
2.These bearings are especially suitable for high dynamic loads or radial-limited installation. They are mounted with a tight interference fit in the housing.
3.Shoulders or snap rings are not required to locate the bearing axially, thus enables a simple and economic design of the housing bore.
4.For various applications such as agricultural and construction equipment, pumps and compressors, and two-cycle engines, among others.
5.NOTE: Install with press machine or special tools instead of hammers because beating may lead to local deformation.
Specification:
Model: HK2012
Drawn Cup Meterial: ST14 Steel
Cage Meterial: ST13 Steel
Needle Roller Meterial: Chromium Steel (GCr15)
Bore Diameter (Fw): 20mm
Outside Diameter (D): 26mm
Width: 12mm
Static Load Capacity (Cor): 10.1kN
Dynamic Load Capacity (Cr): 7.6kN
Maximum Rotational Speed (Oil): 10000rpm
Number of Pack: 1 Pcs
