About this item
- Model: ME-8112; Roller Plunger Limit Switch
- Applying to printer ,3D printer,endstop,CNC router,laser,light switch,wobble light,automatic pantry light switch,garage door,door operated switch,closet door switch,door switch.
- IP65 Protection. Able to withstand some washdowns, shock and vibration
- Designed to control the movement of a mechanical part
- built-in basic switch with good electrical conductivity
Specifications:
Product Name: Limit Switch
Model: TZ-8112
Actuator Type: Roller Plunger Type
Rated Voltage:
AC-15: (Ue/Ie) 250V/6A
DC-13: (Ue/Ie) 220V/0.3A
Contact Configuration: 1NC+1NO
Mounting Hole Size: M5
Mounting Hole Distance: 56 x 21mm / 2.2″ x 0.83″ (L*W)
Note:
The roller plunger can be operated in a wide range by employing a cam, Dog, cylinder, or auxiliary actuator.
Position detection accuracy is high.
Operating Characteristics:
OF max.: 900g
RF min.: 150g
PT max.: 1.5mm
OT min.: 4mm
MD max.: 1mm
OP: 37+/-0.8mm
Features:
- Double circuit limit switch with build-in double reed mechanism.
- Zine alloy and intensive plastic shell, strong and highly rigid construction. (Head and cover snugly fit in box)
- Constructed in small size. Water-proof and oil-proof.
- Built-in basic switch with double spring mechanism, longer mechanical life.
- Smooth operation with greater OT.
- Easy-to-wire circuit opening design.
- This Limit Switch can be widely used in various mechanical to monitor the position of moving parts of machines and control circuit and auxiliary circuit for terminal limit protection.
Product Contents:
2 x Limit Switch with mounting screws
