Theben Binary Input Bus System – 4930235

Binary input for 6 channels, expansion module, expandable with BME 6 T up to a maximum of 18 channels or other MIX expansion modules, DIN rail mounting, width 72 mm, multi-voltage inputs 8-250V AC/DC, auxiliary voltage for potential-free inputs is supplied by the module, all inputs can be used with different voltages. LED display for all inputs.

Functions:

• Blocking object and 2 output objects per channel
• Status when returning from the bus voltage adjustable.

Software functions:

• Switch/push-button
• Dimming
• Shutter
• Transmitter
• Counter function

Specifications

Bus system KNX : Yes
Bus system KNX radio : No
Bus system radio frequent : No
Bus system LON : No
Bus system Powernet : No
Other bus systems : None
Radio frequent bidirectional : No
Mounting method : DRA (DIN-rail adapter)
Width in number of modular spacings : 4
With bus connection : No
Bus module detachable : Yes
LED controlling : No
With LED indication : Yes
Number of inputs : 6
Input voltage (V) : 8 V to 250 V
Type of voltage (input voltage) : AC/DC
External signal voltage necessary : Yes
Degree of protection (IP) : IP20
