This is a Burkert direct operating 3/2 way solenoid valve with 1/4 inch NPT threads and a 24 V AC/DC coil. The valve has a stainless steel housing with FFKM sealing and an orifice size of 3 mm. The circuit function of the solenoid valve is universal. The 3-way valve connects a common port to one of the two other ports, depending on whether the coil is energized. In this version, the pressure can be applied to all ports. As it is direct operating, no pressure differential over the valve is needed to open the valve. Suitable for a pressure of 0 – 6 bar (87 psi) and a maximum temperature of 90 °C (194 °F). The valve has a Kv-value of 0.18 m3/h, this translates to a flow rate of 3 l/min at a differential pressure of 1 bar (for water). In imperial units: Cv = 0, which means 0 GPM @ 1 psi pressure drop. For many applications it is enough to select a valve based on the thread size and orifice diameter. For more accurate sizing, use the Kv-value with our easy to use valve sizing calculator. This model is media separated. This means that the working parts such as the spring are separated from the media by a flexible membrane, which makes it possible to use of slightly contaminated and aggressive media. The stainless steel housing is very durable, strong and resistant to a wide range of chemicals with the exception of chloride solutions. Please note that the internal valve parts, such as the stainless steel plunger and springs, are also in contact with the medium and must be chemically compatible. Consult our chemical resistance chart to verify compatibility of housing and seals with the medium. The manual override feature can be used to commission the system. Thanks to the ATEX and IECEx certification, this solenoid valve is suited for explosive environments. The valve has an IP65 rating if properly connected.
Pros:
- ATEX-certified
- Aggressive media are possible thanks to the media separated design
- The manual override is ideal for commissioning and in case of power outage
- Good protection against the environment thanks to the IP65 rating
- Solenoid valves open and close very fast compared to many other valve types
Cons:
- Solenoid valves are very sensitive to dirt and can only be used with clean liquids and gases
- The coil may get hot when energized. A well ventilated environment is recommended
Series:
The Bürkert solenoid valve type 0330 is a direct-operated solenoid valve, meaning no pressure difference is needed to open the valve. This design is media separated, which allows for complete isolation of your fluid from the valve’s working parts. This feature makes the valve a good solution for aggressive or slightly contaminated media. The valves can be delivered with DN 2 up to DN 5 or with a flange. The pressure range depends on the voltage, but has a maximum of 16 bar. The valve has a maintenance free pivot armature design instead of the common linear translating plunger. The valve is available in IP65 or IP67 protection. The valve has few moving parts, allowing for a long service life due to minimal wear on valve components. The 2/2-way and 3/2-way versions are designed for applications like mixing, diversion, and universal direction of media. The valves are available with different housing materials, such as brass, stainless steel, PP or PVDF in combination with different sealing materials. Finally, there are options for position feedback, bi-stable, vacuum variants, as well as ATEX explosion approved versions.
Please note: this product is made to order and can unfortunately not be returned.
Specifications
Connection size : 1/4 inch
Connection type : Inner thread conical (NPT)
Function : Universal
Voltage : 24 V AC,24 V DC
Material : Stainless steel
Seal material : FFKM
Operation : Direct
Recommended for : Water,Sea water,Combustible gases,Lubricant,Fuel,Oil,Strong acids and bases,Dilute acids and bases,Carbon dioxide,Air
Max pressure (bar) : 6
Features : Manual override,Media separation
Approval : Atex Zone 1,Atex Zone 21,Atex Zone 2,Atex Zone 22,IECEx Zone 1,IECEx Zone 21,IECEx Zone 2,IECEx Zone 22
Valve bore (mm) : 3
Kv value [m3/h] (m³/h) : 0.18
Min temperature (°C) : 5
Max temperature (°C) : 90
Electrical connection : PCB connection
Degree of protection (IP) : IP65
Nominal power (W) : 3
Valve ports/positions : 3/2 way
Voltage-type : AC/DC
Duty cycle : 100%
Frequency : 50/60 Hz
Max. ambient temp. (°C) : 55
Peak power (W) : 40
Valve construction : Valve complete
Valve seat material : Stainless steel
Sealing toward outside material : FFKM
Installation length (mm) : 46
Explosion safety code : ATEX – Ex eb mb IIC T4 Gb,IECEx – II 2 G Ex eb mb IIC T4 Gb,ATEX – Ex mb tb IIIC T130°C Db,IECEx – II 2 D Ex mb tb IIIC T130°C Db
Explosion safety : Ex-Zone 1
Actuation : Pivot
