The square, high-voltage version of our popular NEW TRIA recessed fitting series is available in black, white, or brushed aluminium housings. This recessed spot offers a generous rotation and pivoting range, guaranteeing the ability to individually focus its light beam. It is compatible with both halogen and LED retrofit lamps. Installation is easy with the factory-installed spring clips. The NEW TRIA recessed fitting is ready for direct connection to the 230V alternating current.
Specifications
Suitable for surface mounting : No
Suitable for built-in mounting : Yes
Suitable for wall mounting : No
Suitable for suspended mounting : No
Suitable for ceiling mounting : Yes
Suitable for traverse mounting : No
Suitable for pedestal/floor mounting : No
Suitable for light-track mounting : No
Suitable for clamp-mounting : Yes
Suitable for low voltage cable system : No
Adjustability : Rotating and swivelling
With movement sensor : No
With light sensor : No
Lamp type : LED exchangeable
With light source : No
Suitable for number of lamps : 1
Lamp holder : GU10
Material : Aluminum
Surface protection : Lacquered
Color housing : White
Material cover : None
Surface brushed : No
Voltage-type : AC
Nominal voltage (V) : 230 V to 230 V
Type of control gear : Not required
With control gear : No
Exchangeable control gear : No
Dimming depending on control gear : No
Dimming 0-10 V : No
Dimming 1-10 V : No
Dimming DALI-2 : No
Dimming DALI : No
Dimming DMX : No
Dimming DSI : No
Dimming potentiometer (integrated) : No
Dimming GPRS : No
Dimming LineSwitch : No
Dimming manufacturer’s proprietary system : No
Dimming mains voltage modulation : Yes
Dimming phase cut-off : No
Dimming phase cut-on : No
Dimming programmable : No
Dimming RF : No
Dimming Sine Wave Reduction : No
Dimming Touch and Dim : No
Dimming Zigbee : No
Dimming with push-button : No
No dim function : No
Reflector : Other
Light distributor : Other
Light sharing : Symmetric
Light outlet : Direct
Energy efficiency class : A++
Constant light output (CLO) : No
Degree of protection (IP) : IP20
Protection class : II
Suitable for lamp power (W) : 50 W to 50 W
Max. system power (W) : 50
Color temperature adjustable : No
Luminous flux adjustable : No
Beam angle adjustable : No
Width (mm) : 90
Height/depth (mm) : 110
Length (mm) : 90
Built-in width (mm) : 78
Built-in height/depth (mm) : 125
Built-in length (mm) : 78
Built-in diameter (mm) : 78 mm to 78 mm
Type of wiring : Ending
Connectable conductor cross section (mm²) : 2.5 mm² to 2.5 mm²
Connection type : Other
Luminaire with limited surface temperature, sign “D“ : No
Emergency power supply integrated : No
Suitable for workplace according to EN 12464-1 : No
IFTTT support available : No
Compatible with Apple HomeKit : No
Compatible with Google Assistant : No
Compatible with Amazon Alexa : No
