The siemens miniature circuit breaker has 1p+n pole with c class tripping characteristics. Operating voltage range is from 24 v to 250 v ac also has 6 a current rating. It is touch protected. It has ip20 rating. Operating temperature range is from -25°c to 45 °c. Ccc, imq, vde approved. It is halogen and silicon free. Comes under overvoltage category iii.
Specifications
Built-in depth (mm) : 70
Release characteristic : C
Number of poles (total) : 2
Number of protected poles : 1
Rated current (A) : 6
Rated voltage (V) : 230
Rated insulation voltage Ui (V) : 250
Rated impulse withstand voltage Uimp (kV) : 4
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V (kA) : 6
Voltage-type : AC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V (kA) : 6
Frequency (Hz) : 50 Hz to 50 Hz
Current limiting class : 3
Flush-mounted installation : No
Concurrently switching neutral conductor : Yes
Pollution degree : 2
Additional equipment possible : Yes
Width in number of modular spacings : 1
Ambient temperature during operating (°C) : -25 °C to 60 °C
Connectable conductor cross section multi-wired (mm²) : 0.75 mm² to 16 mm²
Connectable conductor cross section solid-core (mm²) : 0.75 mm² to 16 mm²
Explosion-proof : No
