Off Switch 32A 2-pole On/off switches are designed for mounting on standard rails to control electrical systems. The 5TL1 On/Off switches are specifically used for the switching of lighting, motors, and other electrical devices. They can handle rated currents that range from 32A to 125A. In addition, the 5TL1 device versions may serve as switch disconnectors in accordance with EN 60947-1 and can function as main control switches for the disconnection or isolation of plants as per EN 60204-1.
Regardless of whether you need it for infrastructure or industrial requirements, Siemens provides switchgears for every application and application area. The new design of the 5TL1 On/Off switches ensures that they are seamlessly integrated into the RCCB and MCB series aesthetically.
Key features of the switchgears offered by Siemens include:
- Increased operational safety and system availability due to the ability to separately connect and disconnect the affected circuit.
- Ensured safety during installation with standard reach-around and touch protection.
- Easy removal from the DIN rail or from the bus bar assembly without the need for tools, by simply activating a manual slide.
- A clearly visible switch position indicator.
- Potential to be used as both switch disconnector and main switch.
- Compliance with the provisions of EN 60947-1 and EN 60204-1 for the on/off switches.
- Optimized technology for your safety – exclusively from Siemens.
Specifications
Switching function : Other
Number of contacts as normally open contact : 2
Number of contacts as normally closed contact : 0
Number of contacts as change-over contact : 0
Number of poles : 2
Rated current (A) : 32
Rated voltage (V) : 440
Rated switching capacity (kA) : 0.096
Short-circuit breaking capacity (Icw) (kA) : 10
Voltage-type : AC
With signal lamp : No
Color calotte : Other
Lamp socket : Other
Width in number of modular spacings : 2
Built-in depth (mm) : 70
Degree of protection (IP) : Other
