Schneider Electric STD1000VA Remote Control Dimmer 1000W 4 Digital Inputs – CCTDD20004

The Schneider Electric Acti 9 is a centralized control system designed for buildings. It comes in a compact size of 72x62x85mm and features one dimming function, five channels, and one universal dimming channel. The protection degree, IP20, ensures safety, and the device has a width in modular units of 4. The central function is OFF with a dimming capacity per channel of 1000W. The system further supports module expansion, allowing up to a maximum of 20 units. It is compatible with DIN rails. The STD1000RC/RL-SAE is a dimmer with a capacity of 1000W that can be remotely controlled.

Specifications

Mounting method : DIN rail
Function : Dimmer
Central function OUT : Yes
Group switch : No
Panic function : No
Presence simulation : No
Stair light and forewarn : No
Castor function, number of channels : 0
Number of universal dim channels : 1
Number of dimmer functions : 1
Current surge function, number of channels : 0
Roller shutter-/sun protection control, number of channels : 0
Weekly program : No
Astro program : No
Rain sensor : Yes
Number of channels : 5
Module expansion up to max. number of channels : 20
Control voltage 1 (V) : 12 V to 30 V
Type of control voltage 1 : AC/DC
Rated current (A) : 4
Dim capacity per channel (W) : 1000
Rated voltage (V) : 230 V to 230 V
Rated frequency (Hz) : 50 Hz to 60 Hz
Degree of protection (IP) : IP20
Width in number of modular spacings : 4
Width (mm) : 72
Height (mm) : 85
Depth (mm) : 62
