Schneider Electric Limit Switch – ZCKJ7H29

Schneider Electric limit switch, housing metal, degree of protection (IP) IP65, switching function forced contact with over, execution electrical connection cable entry metric, 2 break contacts, housing according to standard DIN EN 50041, housing shape cube, width sensor 40mm.

Specifications

Width sensor (mm) : 40
Height of sensor (mm) : 77
Length of sensor (mm) : 44
Rated operation current Ie at AC-15, 230 V (A) : 3
Rated operation current Ie at DC-13, 230 V (A) : 0.27
Switching function : Slow-action switch with overlapping
Forced opening : Yes
Number of contacts as normally closed contact : 2
Type of interface : None
Type of interface for safety communication : None
Construction type housing : Cuboid
Material : Metal
Coating housing : Other
Type of control element : None
Alignment of the control element : Other
Electrical connection : Cable entry metrical
Explosion safety gas : None
Explosion safety dust : None
Ambient temperature during operating (°C) : -25 °C to 70 °C
Degree of protection (IP) : IP65
