Schneider Electric GB2 Circuit Breaker – GB2DB12

Schneider Electric GB2 circuit breaker, tripping characteristic other, nom. (measuring) current 6A, voltage type AC, 2 poles (total), width in module units 2, connectable conductor cross-section duck 0.75 – 6mm², 2 protected poles, nom. (measuring) voltage 415V.

Specifications

Built-in depth (mm) : 78
Release characteristic : Other
Number of poles (total) : 2
Number of protected poles : 2
Rated current (A) : 6
Rated voltage (V) : 415
Rated insulation voltage Ui (V) : 415
Rated impulse withstand voltage Uimp (kV) : 4
Voltage-type : AC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V (kA) : 1.5
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V (kA) : 1.5
Frequency (Hz) : 50 Hz to 60 Hz
Current limiting class : 3
Flush-mounted installation : No
Concurrently switching neutral conductor : No
Over voltage category : 3
Pollution degree : 2
Additional equipment possible : No
Width in number of modular spacings : 2
Degree of protection (IP) : IP20
Ambient temperature during operating (°C) : -20 °C to 60 °C
Connectable conductor cross section multi-wired (mm²) : 0.75 mm² to 4 mm²
Connectable conductor cross section solid-core (mm²) : 0.75 mm² to 6 mm²
Explosion-proof : No
