The H 3523 casement window operator is a right handed bronze square body type. It has a 9 in steel arm with a round disc on the tip (some older styles had a small wheel instead of a disc). The disc slides in the H 3529 casement track located on the bottom of the casement window. It is worm gear driven by a 3/8 in crank spindle. The matching crank handle that fits onto the crank spindle and installation screws are included. Mounting holes available are 3-7/8 and 4-3/4 in apart.
Unit: EA
UPC: 049793035233
Model Number: H 3523
Features
- 3-7/8 in and 4-3/4 in mounting holes
- Casement track may also need to be replaced
Additional Information
- Dimensions: 9 in L x 3-7/8 in W x 13-1/4 in H
- Finish: Bronze
- Handle Type: Crank
- Includes: Matching Crank Handle Mounting Screw
- Right Hand/Left Hand: Right
- Suitable for: Older Steel Framed Windows
