Mains-plugtrab pluggable two-pole modular lightning surge protector. Mains-plugtrab is a slim design surge protector designed to protect the low voltage single-phase power supply of very sensitive equipment. It quenches over voltage as a result of inductive or capacitive connections. Its pluggable design allows for easy maintenance (surge protector plug combined with a base for electrical connection). disconnection feature provides continuity of electrical power supply.
Specifications
Nominal voltage AC (V) : 12 V to 12 V
Nominal voltage DC (V) : 24 V to 24 V
Max. continuous voltage AC (V) : 20
Max. continuous voltage DC (V) : 28
Nominal discharge surge current (8/20) (kA) : 10
Nominal load current (A) : 0.3
Voltage protection level core/earth (V) : 80
Limiting frequency (MHz) : 60
Mounting method : Other
Connection 1 : Other
Pro-active thermo-control : No
With remote signalling contact : No
Signalling at the device : None
Explosion-tested version : No
