The OCS floorbox and floor trough lid sets are suitable for floor troughs, hollow and double floors. They come in a sleek black color labeled with RAL number 9005. These covers are ideal for floor maintenance as they are designed for dry conditions. The lid set features a carpet protection frame. The installation diameter is 127mm, while the outer diameter is 140mm. Also available is an OCS tile duct with a 127mm diameter that’s ideal for routing cables through a hollow floor space. The cable openings can be infinitely adjusted and optionally sealed with neoprene rubber. However, this variant doesn’t come with a clamp.
OCS offers an ideal solution for routing cables through a hollow space floor with tile feedthroughs. The tile feedthroughs are available in various diameters of respectively 102mm, 127mm, 169mm, and 209mm.
Specifications
Model : Round
Suitable for sub-floor duct : Yes
Suitable for hollow floor : Yes
Suitable for double floor built-in : Yes
Depth of flooring recess (mm) : 0
Floor maintenance : Dry
Frame model : Carpet protection frame
Built-in diameter (mm) : 127
Outer-diameter (mm) : 140
Material : Other
Color : Black
