Motor Bearing 5mm to 6mm Joint Helical Beam Coupler Coupling 20mm Dia 25mm Long

About this item

• Shaft Usage: 5mm to 6mm / 0.19 to 0.24 inch
• Material: Aluminum alloy; Size: 25x20mm/ 0.98×0.79inch( L*D)
• Feature: Screw Type(Coiling Clamping); Main Color: Silver tone
• Flexibility of coupling shaft removes stress between the motor and driving components.
• The shaft couplers are widely applied to small CNC machines encoding and 3D printers Z shaft coupling, simplifies the debugging difficulty.

Description:
5mm to 6mm shaft usage diameter, 25mm length, 20mm diameter, set screw type coupling.
Zero backlash. One-piece metallic spring coupling. For little torque shaft connect.
Absorption of parallel, angular misalignments and shaft end-play by spring action.
Widely used in drive systems for encoders, instrumentation,lead screws, small pumps, feed rollers and anywhere light to medium duty, torsionally flexible coupling is required.

Specification:
Feature: Screw Type(Coiling Clamping)
Size: 25x20mm/ 0.98×0.79inch( L*D)
Material: Aluminum alloy
Main Color: Silver tone
Weight: 19g

Package Content:
1 x Shaft coupling
