This three-speed switch from Jung is suitable for controlling motors with three speeds, namely 1-2-3. The three-position switch controls a fan, for example. This three-position switch has no zero position. The basic element is fixed by screw fixing and must be finished with a suitable central plate and cover frame. This Jung three-position switch is suitable for the following covers: AS / A range: anan no. 1541 . CD range: anan number. CD 1541 . SL range: anan number. SL 1541 . LS range: anan nummer. LS 1941 . . 1941 .
Specifications
Assembly arrangement : Basic element
Method of operation : Turn button
Wiring system : Circuit 2 – 1 -3
Mounting method : Flush mounted (plaster)
Material : Other
Material quality : Other
Halogen free : Yes
Surface protection : Untreated
Surface finishing : Matt
RAL-number (similar) : 0
Transparent : No
Suitable for degree of protection (IP) : IP2X
Rated current (A) : 16
Nominal voltage (V) : 250
Type of fastening : Mounting with screw
Min. depth of built-in installation box (mm) : 40
