For 6, and 8, pin plug, RJ 12, RJ 45, ISDN, compatible. Type conforming to DIN EN 60 603, 7, IEC 603, 7. The UAE, system is suitable for transmission values up to 16 MHz suitable, which is also for cat. 3, boxes are required. The heart of the system is a socket for 8, pole plug with automatically acting, spring-loaded, side reduzier elements, which guarantee an exact fit, including the narrower 6, pole RJ 12, plug in the sockets element.
Specifications
Surface mounting : No
Flush-mounted installation : Yes
Duct installation : Yes
Floor box/sub-floor mounted : No
Assembly arrangement : Basic element
With buses/couplings : Yes
Suitable for number of connectors : 1
Category : 3
Connection type : Screw
Shielded buses : Yes
Shielded housing : No
Separate earthing connection : No
With label space : No
Separate strain relief : No
Mounting method shielding connection : None
Outlet direction : Straight
With dust cover : No
With terminal resistor : No
Mechanical coding : No
