Jahn-A Bracket / A Clamp

This Jahn-A Bracket is fabricated from high strength steel with a cad plated eccentric and painted body. The 5/8″ take-up of the eccentric compensates for minor lumber variations in thickness. This Jahn-A Bracket can be utilized to hold a single horizontal wale or a single vertical stud with any type of wall form; round, curved, battered, beam and/or columns.
The Jahn-A Bracket can be installed before or after the wales have been positioned. The slots in the bracket allow it to slip over the snap tie end without laborious threading through holes. When properly installed, the ACLMP bracket will not loosen from internal vibration of the concrete. Pressure from the bracket is against the 2 x 4 instead of the plywood. The ACLMP bracket uses 4-3/4″ L&W snap ties, is easy to install and strip, requires no nailing and is very fast.
