Hager VISION Circuit Breaker – VKS03SF

This stove group expansion kit from Hager’s Vision series is quick and easy to install in Hager Vision group boxes. The expansion set includes wiring. The Hager Vision expansion set fits both the VKS and VKG from the Vision series.

Specifications

Built-in depth (mm) : 70
Release characteristic : B
Number of poles (total) : 2
Number of protected poles : 1
Rated current (A) : 16
Rated voltage (V) : 400
Rated insulation voltage Ui (V) : 500
Rated impulse withstand voltage Uimp (kV) : 4
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V (kA) : 6
Voltage-type : AC
Frequency (Hz) : 50 Hz to 60 Hz
Current limiting class : 3
Flush-mounted installation : Yes
Concurrently switching neutral conductor : Yes
Over voltage category : 3
Pollution degree : 2
Additional equipment possible : No
Width in number of modular spacings : 2
Degree of protection (IP) : IP20
Ambient temperature during operating (°C) : -25 °C to 70 °C
Connectable conductor cross section multi-wired (mm²) : 0.75 mm² to 10 mm²
Connectable conductor cross section solid-core (mm²) : 0.75 mm² to 16 mm²
Explosion-proof : No
