Hager Berker TS Oval Wall Box – 1809

The Hager Berker TS is a black, modular connector that falls under Category 5E. It features a jack design and is a part of the chassis component. The connector type is RJ45, which is shielded. This product is suitable for solid core cables and round cables. The product also includes a built-in box suitable for Berker TS glass cover plates.

Specifications

Mounting method : Flush mounted (plaster)
Shape : Oval
Construction type : Device connection box (round/square)
Model : Single
Provided with revolving ring : No
Connectable : Yes
Equipped with : None
Length (mm) : 140
Width (mm) : 67.2
Depth (mm) : 41.7 mm to 41.7 mm
Internal depth (mm) : 40
For number of electric fittings : 2
Mounting switching equipment : Screwing
With screws : No
Housing feed-through by break-out opening : Yes
Housing feed-through by seal membrane : No
Housing feed-through by nozzle : No
Housing feed-through by step membrane : No
For tube diameter : 20 mm
Suitable for cable diameter (mm) : 10.4 mm to 10.4 mm
Pipe locking : No
Pipe locking optional : No
Inlet from the rear : Yes
Number of inlets : 12
Number of included spouts : 0
Material : Plastic
Halogen free : No
Surface protection : Untreated
Color : Black
Degree of protection (IP) : IP2X
Degree of protection (NEMA) : 1
Cover model : None
Transparent cover : No
Sealable : No
Circuit integrity : None
With screening : No
Air tight : No
Max. conductor cross section (mm²) : 2.5
Number of poles of the clamp : 0
Clamp position fixed : No
Luminaire hook mounting : No
Nozzle : Other
With nail lugs : No
Special application : None
