The Hager Berker heating actuator for the bus system has a switching voltage of 230 – 240V, and has 6 outputs. It features valve protection functionality and has a protection rating (IP) of IP20. The width is 4 module units, and it includes a bus connection. This actuator is designed for the KNX bus system and is energy-saving. It allows for manual switching and allows a maximum switching current of 16A under a resistive load. Additionally, the KNX room actuator has 4 make contacts of 16A plus 2x actuator drive.
Specifications
Bus system KNX : Yes
Bus system KNX radio : No
Bus system radio frequent : No
Bus system LON : No
Bus system Powernet : No
Other bus systems : None
Radio frequent bidirectional : No
Mounting method : DRA (DIN-rail adapter)
Width in number of modular spacings : 4
With bus connection : Yes
Bus module detachable : No
Correcting variable consistent : Yes
Correcting variable switching : Yes
Valve protection function : Yes
Manual switch : Yes
Max. switching current (resistive load) (A) : 16
Number of outputs : 6
Max. output current (A) : 0.05
Switching voltage (V) : 230 V to 240 V
Degree of protection (IP) : IP20
