Grove Cast Iron Right Angle Worm Gear Reducer is designed for a wide variety of applications requiring slow speed and high torque, ideal for conveyors, material handling, textile machines, packaging machinery, etc.
FEATURES:
- Heavy duty cast iron housing
- Factory-filled premium Mobil Glygoyle 460 polyalkalene lubricant
- Precision machined mounting surfaces
- O-rings on input and output covers
- Viton double lip seals provide extended life
- NEMA C input flange, Push-off holes
- Bronze worm gear chill cast from high quality bronze
- Tapered roller bearings
- Premium Grade 5 assembly bolts throughout
- Mounting dimensions are interchangeable with most industry standard reducers
Specifications
|
Max Input HP @1750: |
2.6 |
|
Output RPM @1750: |
350 |
|
Reduction Ratio: |
5:1 |
|
Torque (lb-in)@1750rpm: |
436 |
|
Overhung Load (lbs.): |
1200 |
|
Shaft Center Distance: |
1.75 |
|
Shaft Center Height: |
2.06 |
|
Mount Footprint: |
2.75” x 4.19” |
|
NEMA Input Mounting: |
143-5TC |
|
Mount Style: |
HMQ |
