GROVE Gearing products are Non-Returnable. Once the order is placed it cannot be canceled. Standard lead times are 5-10 business days. For urgent expedited orders please contact our office for availability.
Specifications
|
Max Input HP @1750: |
11.13 |
|
Output RPM @1750: |
116 |
|
Reduction Ratio: |
15:1 |
|
Torque (lb-in)@1750rpm: |
5508 |
|
Overhung Load (lbs.): |
3190 |
|
Shaft Center Distance: |
4.25 |
|
Shaft Center Height: |
4.44 |
|
Mount Footprint: |
5.00″ x 8.50″ |
|
NEMA Input Mounting: |
213-5TC |
|
Mount Style: |
HM |
