Gira System 55 Switchgear Insert – 040227

This stereo loudspeaker socket outlet from the System 55 series by Gira has a connectable cable cross-section of up to 1.5mm². For cable cross-section up to max. 10mm². With screw terminals. Use as a base element for High-End Speaker Connector (WBT) 0091 00 and data cap 0870 .

Specifications

Assembly arrangement : Basic element with central cover plate
Utilization : Loudspeaker connection
Support ring : Yes
With dust cover : No
With hinged lid : No
Imprintable label : Without indication field
With imprint : No
Mounting method : Flush mounted (plaster)
Material : Plastic
Material quality : Thermoplastic
Halogen free : Yes
Anti-bacterial treatment : No
Surface protection : Other
Surface finishing : Matt
Color : White
RAL-number (similar) : 9010
Transparent : No
Type of fastening : Mounting with claw and screw
With buses/couplings : No
With strain relief : No
Shielded buses : No
Shielded housing : No
Luster terminal : No
With lighting : No
Suitable for degree of protection (IP) : IP20
