FFC FPC 25 Pin 0.3mm Pitch Adapter DIP 2.0mm 2.54mm PCB Converter Board for LCD

About this item

• [SPECIFICATION]: Flexible flat cable FFC FPC connector adapter 25 Pin 0.3 mm to 2.0mm/2.54mm pitch DIP PCB converter.
• [FEATURE]: FPC extension Board PCB support, single side of the flip-up interface.
• [NOTE]: The carrying board is original for a 51 pin seat, but the board you will purchase is ready for a 25 pin converter seat.
• [TYPE]: for 0.3mm pitch flat cable, 25 Pin below, pitch 2.0mm and 2.54mm dip can be applied.
• [APPLICATION]: Applying to various of the LCD screen, such as digital cameras, digital camcorders, laptops, LCD TVs, LCD monitors, etc.

Description:

1.These PCB circuit board adapters for FPC/FFC IC package with exposed pad

2.The PCB board is the single side, the flat cable port for pin pitch size 0.3mm and 25 pin, and the DIP pitch is 2.0mm and 2.54mm.

3.Applying to various of the LCD screen, such as digital cameras, digital camcorders, laptops, LCD TVs, LCD monitors, etc.

Note:
The carrying board is original for a 51 pin seat, but the board you will purchase is ready for a 25 pin converter seat.

Specification:

Pins: 25 Pins

Product type: PCB Support

FPC Connector Pitch: 0.3mm

DIP Pitch: 2.0mm / 2.54mm

Total Size: 67 x 30 x 1.15 mm / 2.64 x 1.18 x 0.05 inch (L*W*H)

Package Content :

Package Content: 1 x 25 Pin FFC Cable Adapter
