Grounding terminal screw standard. Combination switch with additional switch has 120/277 V rating, ideal for fluorescent lighting fixtures typical in commercial applications. 0.050 in thick steel mounting strap zinc-plated for corrosion resistance. Break-off provision for wiring both devices on same circuit or on separate circuits. Terminal screws backed out and ready for wiring. Side wire terminals accept up to #10 solid or stranded wire. Combination slot/Phillips head mounting and terminal screws. Switches meet all UL 20 requirements. UL Listed.
Unit: EA
UPC: 032664161605
Model Number: 276W-BOX
Features
- Grounding terminal screw standard
- Receptacles have triple wipe line contacts and double wipe ground contacts to insure long-term plug retention
- Thick steel mounting strap is zinc-plated for corrosion resistance
- Break-off provision for wiring both devices on same circuit or on separate circuits
- Terminal screws backed out and ready for wiring
- Pilot light may be wired to indicate power on or power off
- Combination Phillips/slotted screw heads ensure faster installation
Additional Information
- Actuator Type: Toggle
- Color: White
- Current Rating: 15 A
- Housing Material: Steel
- Mounting Type: Strap
- Number of Poles: 1
- Switch Operation: Back and Side
- Terminal Type: Screw
- Voltage Rating: 120/277 V
