The Eaton Industries XBoard XVTL EP profile for cabinets/desks is made of steel, with a length of 115mm. It is designed in a metric style and utilizes a screw fastening method. The profile height of the supporting rail is also 115mm. This assembly is factory finished and type-tested for surface mounting, with a surface finished in galvanized zinc. The EP system is the standard system chosen for flush-mounting, ensuring its reliable and efficient performance.
Specifications
Length (mm) : 25
Width (mm) : 16
Height (mm) : 115
Slit width (mm) : 9.5
Material thickness (mm) : 2
Profile shape : U-profile
Model : Singular profile
Type of perforation : 3 sides punched
Hole width (mm) : 3.6
With toothing : No
Snap-off : No
Load bearing capacity (kN) : 0
Area moment of inertia Iy (cm4) : 0
Area of inertia Iz (cm4) : 0
Moment of resistance Wy (cm³) : 0
Moment of resistance Wz (cm³) : 0
Suitable for circuit integrity : No
Material : Steel
Material quality : Other
Surface protection : Galvanic/electrolytic zinc plated
Color : Other
RAL-number : 0
Weight (kg) : 0.094
