The Eaton xPole Z-TN230/2S2O Installation Relay features a convenient ON-AUTO-OFF switch. Operating at 230V and 50Hz, the device is rated for a 20A current load. It is equipped with 2 Normally Open (2NO) and 2 Normally Closed (2NC) contacts. The installation relay has a compact design with a size of 2 Din rail module units (2TE), facilitating easy setup in various electrical installations.
Specifications
Function : Mechanical
Mounting method : DIN rail
Width in number of modular spacings : 2
Built-in depth (mm) : 60
Number of contacts as normally open contact : 2
Number of contacts as normally closed contact : 2
Number of contacts as change-over contact : 0
Control voltage 1 (V) : 230 V to 230 V
Type of control voltage 1 : AC
Frequency control voltage 1 (Hz) : 50 Hz to 50 Hz
Control voltage 2 (V) : 0 V to 0 V
Type of control voltage 2 : AC/DC
Frequency control voltage 2 (Hz) : 0 Hz to 0 Hz
Rated current (A) : 20
Supply voltage (V) : 250 V to 250 V
Voltage type of supply voltage : AC
Max. incandescent lamp load (W) : 0
Max. load fluorescent lamp (VA) : 0
Max. load fluorescent lamp (Duo circuit) (VA) : 0
Max. load fluorescent lamp (parallel compensated) (VA) : 0
Max. switching current (cos phi = 0.6) (A) : 0
