Eaton NZMB1-M50 Circuit Breaker 3P 50A 25kA IEC – 265711

The Eaton Industries NZMB M power circuit breaker is designed to provide optimal performance with a nominal continuous current of 50A and a nominal disconnecting power of 53kA at 400. It features a setting range for overload protection of 300 – 500A, and a similar setting range for un-delayed short circuiting. Its main power circuit connectivity is facilitated through a screw connection, and it comes with 3 poles. It is part of the NZM..-M series, which is suitable for the IEC market. The breaker’s flexibility is enhanced by modular function groups. Additionally, it comes with thermomagnetic releases for motor protection and adheres to IEC/EN 60947-4-1 and IEC/EN 60947-2 circuit breakers requirements. Other features include phase-failure sensitivity and tripping class 10A.

Specifications

Overload release current setting (A) : 40 A to 50 A
Adjustment range undelayed short-circuit release (A) : 400 A to 700 A
With thermal protection : Yes
Phase failure sensitive : Yes
Switch off technique : Thermomagnetic
Rated operating voltage (V) : 440 V to 440 V
Rated permanent current Iu (A) : 50
Rated operation power at AC-3, 230 V (kW) : 15
Rated operation power at AC-3, 400 V (kW) : 22
Type of electrical connection of main circuit : Other
Type of control element : Rocker lever
Device construction : Built-in device fixed built-in technique
With integrated auxiliary switch : No
With integrated under voltage release : No
Number of poles : 3
Rated short-circuit breaking capacity lcu at 400 V, AC (kA) : 18.5
Degree of protection (IP) : IP20
Height (mm) : 145
Width (mm) : 90
Depth (mm) : 88
