The Eaton Industries Xpole motor-protective circuit-breaker features both thermal overload and magnetic short-circuit release designed for controlling and safeguarding three-phase motors with power outputs up to 15 kW (380/400 V) or other applications with currents reaching up to 40 A. It can also function as a main switch with isolating characteristics according to IEC/EN 60947 standards. The contact position is clearly indicated by a red/green display.
Specifications
Overload release current setting (A) : 1 A to 1.6 A
Adjustment range undelayed short-circuit release (A) : 16 A to 21 A
With thermal protection : Yes
Phase failure sensitive : No
Switch off technique : Magnetic
Rated operating voltage (V) : 400 V to 400 V
Rated permanent current Iu (A) : 1.6
Rated operation power at AC-3, 230 V (kW) : 0
Rated operation power at AC-3, 400 V (kW) : 0.55
Type of electrical connection of main circuit : Screw connection
Type of control element : Rocker lever
Device construction : Complete device in housing
With integrated auxiliary switch : No
With integrated under voltage release : No
Number of poles : 2
Rated short-circuit breaking capacity lcu at 400 V, AC (kA) : 10
Degree of protection (IP) : IP20
Height (mm) : 75
Width (mm) : 36
Depth (mm) : 80
