Eaton Motor Protective Circuit Breakers 0.25-0.4A 3P – 248404

The Eaton Industries Xpole motor-protective circuit-breaker is equipped with a thermal overload release and a magnetic short-circuit release designed to switch and protect three-phase motors with outputs of up to 15 kW (380/400 V) or loads with current up to 40 A. It can be used as a main switch and has isolating characteristics in accordance with IEC/EN 60947. The circuit breaker also features a contact position display with a red/green color indicator.

Specifications

Overload release current setting (A) : 0.25 A to 0.4 A
Adjustment range undelayed short-circuit release (A) : 3.1 A to 4.8 A
With thermal protection : Yes
Phase failure sensitive : No
Switch off technique : Magnetic
Rated operating voltage (V) : 400 V to 400 V
Rated permanent current Iu (A) : 0.4
Rated operation power at AC-3, 230 V (kW) : 0
Rated operation power at AC-3, 400 V (kW) : 0.09
Type of electrical connection of main circuit : Screw connection
Type of control element : Rocker lever
Device construction : Complete device in housing
With integrated auxiliary switch : No
With integrated under voltage release : No
Number of poles : 3
Rated short-circuit breaking capacity lcu at 400 V, AC (kA) : 10
Degree of protection (IP) : IP20
Height (mm) : 75
Width (mm) : 54
Depth (mm) : 80
