Eaton Moeller series xPole – PLS6/M MCB. PLS6, 3-pole, tripping characteristic: C, rated current In: 4 A, rated switching capacity IEC/EN 60898-1: 6 kA.
Specifications
Release characteristic : C
Number of poles (total) : 3
Number of protected poles : 3
Rated insulation voltage Ui (V) : 440
Voltage-type : AC
Current limiting class : 3
Flush-mounted installation : No
Concurrently switching neutral conductor : No
Additional equipment possible : Yes
Width in number of modular spacings : 3
Connectable conductor cross section multi-wired (mm²) : 1 mm² to 25 mm²
Connectable conductor cross section solid-core (mm²) : 1 mm² to 25 mm²
