EATON INDUSTRIES PLH Circuit Breaker – 248067

Eaton Industries PLH T circuit breaker, tripping characteristic C, connecting neutral, nom. (measuring) current 125A, voltage type AC, 4 poles (total), width in module units 6, secondary device possible, connectable conductor cross-section duck 2.5 – 50mm², 3 protected poles, nom. (measuring) voltage 400V.

Specifications

Release characteristic : C
Number of poles (total) : 4
Number of protected poles : 3
Rated insulation voltage Ui (V) : 440
Voltage-type : AC
Current limiting class : 3
Flush-mounted installation : No
Concurrently switching neutral conductor : Yes
Additional equipment possible : Yes
Width in number of modular spacings : 6
Connectable conductor cross section multi-wired (mm²) : 2.5 mm² to 50 mm²
Connectable conductor cross section solid-core (mm²) : 2.5 mm² to 50 mm²
