The Eaton Industries XComfort heating actuator operates in a switch voltage range of 196-253V. It features a single output, valve protection function, and is compatible with other xComfort bus systems. It also has an IP20 degree of protection and includes a bus connection. The device operates on radio frequency bus system, provides energy efficiency, manual switching, and can manage a maximum switching current of 16A with ohmic load. As a Heating Plug 12A, it is suitable for all electric heaters and panels. Integration with wireless temperature sensors or a smart device such as Smart Home Controller is possible. It features heating profiles for easy selection of heating type, long-life hybrid switching technology for high-performance switching, and PWM-based heating control. Additionally, it comes with integrated energy measurement, supports wireless floor temperature sensor for overheat protection, and has an emergency mode for temperature sensor failure.
Specifications
Bus system KNX : No
Bus system KNX radio : No
Bus system radio frequent : Yes
Bus system LON : No
Bus system Powernet : No
Other bus systems : xComfort
Radio frequent bidirectional : Yes
Mounting method : Surface mounted (plaster)
Width in number of modular spacings : 0
With bus connection : Yes
Bus module detachable : No
Correcting variable consistent : Yes
Correcting variable switching : No
Valve protection function : Yes
Manual switch : Yes
Number of digital inputs : 0
Max. switching current (resistive load) (A) : 16
Number of outputs : 1
Max. output current (A) : 12
Switching voltage (V) : 196 V to 253 V
Degree of protection (IP) : IP20
Min. depth of built-in installation box (mm) : 0
