Straight blade receptacle. Meets all UL and CSA specifications. Triple wire line contacts provide excellent long-term plug retention. High impact and chemical-resistant nylon face. Side wire terminals accept up to #10 solid or stranded wire. Terminal screws backed out. 20 A, 250 V.
Unit: EA
UPC: 032664184000
Model Number: 1876B-BOX
Features
- Galvanized steel, wraparound yoke mounting strap for excellent assembly security
- Extra length or width helps reach large panel cutouts for code compliance
- Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper used
- Screw catch feature on duplex devices speeds mounting of wallplates
Additional Information
- Color: Brown
- Current Rating: 20 A
- Dimensions: 3.28 in L x 1.31 in W x 0.83 in D
- Material: Nylon
- Mounting Type: Flush
- NEMA Configuration: NEMA 6-20R
- Number of Poles: 2
- Number Of Wires: 3
- Operating Temperature: -4 to 140 deg F
- Voltage Rating: 250 V
- Wire Size: 14 to 10 AWG
- Wiring Type: Side
