Doepke Kamrail – 09920122

Doepke comb rail, diameter 10mm², length 140mm, rated continuous current Iu 63A, suitable for devices with zero yellow, electrical connection design fork, 3 phases, suitable for number of devices 2, 4 poles, width in module units 8, division size 17.5mm, insulated, max. Rated operating voltage Ue 690V.

Specifications

Number of phases : 3
Number of poles : 4
Suitable for number of devices : 2
Module width (mm) : 17.8
Cross section (mm²) : 10
Length (mm) : 140
Width in number of modular spacings : 8
Rated permanent current Iu (A) : 63
Electrical connection : Fork
Insulated : Yes
Rated surge voltage (kV) : 4.5
Conditioned rated short-circuit current Iq (kA) : 15
Max. rated operation voltage Ue (V) : 500
Rated short-time withstand current lcw (kA) : 15
Suitable for devices with N-conductor : Yes
Suitable for devices with auxiliary switch : No
Color : Grey
