Dehn Adjustable Ball Head Cap D 20mm For Cables 16-120mm2 – 772331

This is an adjustable ball head cap with a hexagon shaft that can be used as a phase or earth connecting element, conforming to EN/IEC 61230 (DIN VDE 0683-100) for fixed ball points. It’s suitable for attaching to earthing and short-circuiting devices. The cap can be adjusted 4 times at 90° angles and has an anti-rotation feature (PK1). With a maximum short-circuit current of 33.5kA, it can accommodate wire cross sections from 16 to 120mm². The connecting method involves a 20mm fixed ball point, and the control rod spindle is secured with a cross pin.

Specifications

Max. short circuit current (kA) : 33.5
For wire cross section (mm²) : 16 mm² to 120 mm²
Connection type : Fixed ball point 20 mm
Anti-rotation protection : Yes
Admission of the activation rod : Spindle with cross pin
Application : Phase-side
