Cartridge fuses are used to protect motors and branch circuits where higher amps or volt ratings are required. General-Purpose fuses have no time-delay and protect fuse panels, appliances and branch circuits.
Unit: CD 2
UPC: 051712111065
Model Number: BP/NON-40
Features
- Protect lighting, heating and other circuits not subject to temporary surges and where available short-circuit currents are relatively low
- NON one-time fuses do not have any appreciable degree of time delay and thus should not be specified in circuits where large transients or motor overloads occur
- Basic protection 250 V NON Class K5 and H general-purpose, non-current-limiting, one-time fuses
Additional Information
- Body Material: Melamine
- Current Rating: 40 A
- Diameter: 0.81 in
- Element Type: Single
- Fuse Type: Cartridge
- Interrupt Rating: 50 kA
- Length: 3 in
- Rejection/Non-Rejection: Non-Rejection
- Voltage Rating: 250 VAC 125 VDC
