Aviation Connector, 28mm 14P Y2M28-14TK Waterproof Male Wire Panel Power Chassis Metal Fittings Connector Aviation Silver Tone

About this item

• Terminal Number: 14 Terminals; Contact Material: Brass with silver plating;
• Opening size: 28mm/1.1″; Color: Silver Tone, Black; Qualification: CE;Temperature Range: -25~80C; Total Size: 2.75mm/1.48″;Net Weight: 85g
• Model: Y2M28-14TK; Contact Resistance: <1.5ohm; Insulation Resistance:>2000Mohm
• The Wire Hole Diameter: 17.6mm/0.69″; Terminal Diameter: 2.5mm/0.1″; Mounting Hole Distance: 25mm/1″
• The Aviation connector is widely used in signal and electronic connector of aviation, space light, post and telecommunications, computer, navigation and various kinds of instruments, CNC machine etc

Description:
Widely used in aviation, navigation, construction site, port, dock, and some other sealing electronic equipment.
Design with a black short rubber tube on the end, mainly used for the electrical connection between the cables.
Waterproof and really a great apparatus electronic connector.
Specifications:
Product Name:  Aviation Connector
Model: Y2M28-14TK
Terminal Number: 14 Terminals
Thread Dia: 28mm/1.1inch
Net Weight:  85g
Shell Material: Zinc alloy with chrome plating
Contact Material: Brass with gold plating
Color: Silver Tone,Green
Contact Resistance: 2000Mohm
Temperature Range: -25~80C
Qualification: CE
Package Include:
Package Content: 1 x Aviation Connector
