the Quiet exhaust fan series features an energy efficient fluorescent light with a contoured low profile grill, a moonstone glass lens and a night light. All can be wired to operate separately and the electronically balanced centrifugal blower wheel assures maximum ventilation at minimum sound. Spring-loaded damper protects against back drafts. UL listed for installation over a tub or shower on a GFCI circuit. HV12100 Certified. Standard 26 W maximum compact fluorescent four-pin quad tube lamp, 7 W night light, Motors suitable for continuous operation. 4 in metal duct collar with back draft damper provides a solid ducting connection and prevents drafts from entering the room. White polymeric grill 11 x 13-3/4 in. Polymeric dual blower wheel. (Use Orgill Sku 544.6042 for replacement bulb).
Unit: EA
UPC: 083162210005
Model Number: AK100L
Features
- White, polymeric grill secured in place with torsion springs, easily removed if necessary
- Blower wheel, balanced polymeric dual inlet blower wheel 51/4 in Dia x 27/8 in D, 30 paddles, secured in place via press fit
- Heavy-duty motor, plug-in, four-pole motor, life time lubrication, suitable for continuous operation
- Duct collar plastic collar for 4 in duct connection, comes complete with built-in non-metallic back draft damper for quiet operation
- Ventilating area for bathrooms up to 100 sq-ft and for other rooms up to 125 sq-ft
- Electrical connections 1/2 in electrical knockouts provided
- Easily installs using the included adjustable hanging brackets
- 4 in plastic damper protects against backdrafts and ensures quiet operation
Additional Information
- Air Flow Rate: 100 cfm
- Color: White
- Current Rating: 0.6 A
- Dimensions: 9.4 in L x 10.88 in W x 7.88 in H
- Duct Size: 4 in
- Frequency Rating: 60 Hz
- Grill Shape: Round
- Includes: Blower Damper and Duct Collar Grill with Glass Light Lens and Hanger Bars
- Material: Metal
- Sound Level: 2.5 sones
- Speed Rating: 984 rpm
- Voltage Rating: 120 V
- Wattage Rating: 7 W
