ABB System pro M compact Switch-Disconnector – 2CDD284101R0025

Abb System pro M compact SD switch-disconnector, design as main switch, max. Rated operating voltage Ue at A 440V, operating voltage (measuring voltage) 12 – 462V, rated continuous current Iu 25A, rated continuous current, AC-21, 400 V 25A, rated power at AC-3, 400 V 9kW, rated power, AC-23, 400 V 9kW.

Specifications

Version as main switch : Yes
Version as maintenance-/service switch : No
Version as safety switch : No
Version as emergency stop installation : No
Max. rated operation voltage Ue AC (V) : 440
Rated operating voltage (V) : 12 V to 462 V
Rated permanent current Iu (A) : 25
Rated operation power at AC-3, 400 V (kW) : 9
Rated operation power at AC-23, 400 V (kW) : 9
Conditioned rated short-circuit current Iq (kA) : 25
Number of poles : 4
Number of auxiliary contacts as normally closed contact : 0
Number of auxiliary contacts as normally open contact : 0
Number of auxiliary contacts as change-over contact : 0
Motor drive optional : Yes
Motor drive integrated : No
Device construction : Built-in device fixed built-in technique
Suitable for floor mounting : Yes
Suitable for front mounting 4-hole : No
Suitable for front mounting center : No
Suitable for distribution board installation : Yes
Suitable for intermediate mounting : Yes
Color control element : Red
Type of control element : Rocker lever
Interlockable : Yes
Type of electrical connection of main circuit : Screw connection
Degree of protection (IP), front side : IP20
