This 2-pole ABB S200 series switch-disconnector can be used as both a switch-disconnector and a main switch. The rated continuous current is 25A. Furthermore, this switch-disconnector has a control element with a gray color. This switch is known for its locking capability and floor mounting option. The operating voltage (measurement voltage) is 380 to 440 V.
Specifications
Version as main switch : Yes
Version as maintenance-/service switch : No
Version as safety switch : No
Version as emergency stop installation : No
Max. rated operation voltage Ue AC (V) : 400
Rated operating voltage (V) : 380 V to 440 V
Rated permanent current Iu (A) : 25
Number of poles : 2
Number of auxiliary contacts as normally closed contact : 0
Number of auxiliary contacts as normally open contact : 2
Number of auxiliary contacts as change-over contact : 0
Motor drive optional : No
Motor drive integrated : No
Device construction : Built-in device fixed built-in technique
Suitable for floor mounting : Yes
Suitable for front mounting 4-hole : No
Suitable for front mounting center : No
Suitable for distribution board installation : Yes
Suitable for intermediate mounting : Yes
Color control element : Grey
Type of control element : Rocker lever
Interlockable : Yes
Type of electrical connection of main circuit : Screw connection
Degree of protection (IP), front side : IP20
