ABB Busch-Jaeger Motion Detector Bus System – 2CKA006132A0338

For installing a Busch-Presence detector mini KNX 6131/20-xxx(-500) or a Busch-Presence detector mini premium KNX 6131/21-xxx(-500).

Specifications

Bus system KNX : Yes
Bus system KNX radio : No
Bus system radio frequent : No
Bus system LON : No
Bus system Powernet : No
Other bus systems : None
Radio frequent bidirectional : No
Model : Other
Mounting method : Flush mounted (plaster)
Material : Plastic
Material quality : Thermoplastic
Surface protection : Untreated
Surface finishing : Matt
Color : White
RAL-number (similar) : 9016
Transparent : No
With bus connection : No
Substation input : No
Creep-under protection : No
Operation mode switch : No
Animal zone : No
Staircase monitoring : No
Response value luminosity adjustable : No
Teach-function for response value luminosity : No
Switch-off delay self-learning : No
Optimum mounting height (m) : 6
Max. transmission range sideways (m) : 5
Max. transmission range frontally (m) : 15
Diameter detection range on floor (m) : 5
Detection angle vertical (°) : 10 ° to 10 °
Detection angle horizontal (°) : 0 ° to 360 °
Number of channels : 2
Min. switch-on time (s) : 10
Max. duty cycle (min) : 1092
