APPLICATIONS: Incorporates a radial flux design which delivers high torque, high efficiency and increased power density, providing incredible system maximization and the potential to eliminate sheaves and belts, gearboxes and chains in certain applications.
FEATURES:
- Ultra Efficient™ Premium-Plus exceeds NEMA Premium® (IE4)
- Class H MAX GUARD® insulation system
- Normally closed thermostats (one per phase, Class F)
- High power density, low weight design
- UL, CSA and CE
- Optional terminal block shown
- Provisions for optional “BCP” (Bearing Current Protection)
- Three year warranty
- Requires Drive for Operation
Specifications
|
Brand: |
Marathon |
|
Application: |
Permanent Mag AC |
|
Output HP: |
5 |
|
Output KW: |
3.7 |
|
Output RPM: |
1800 |
|
Frame Size NEMA: |
184TC |
|
Mount NEMA: |
C Face With Base |
|
Enclosure NEMA: |
TENV |
|
Enclosure IEC: |
IP54 |
|
Voltage: |
230/460 |
