APPLICATIONS: Used on Crop Dryer with air over/fan on shaft designs.
FEATURES:
- Dripproof air over
- 1 1/8″ output shaft diameter
- Class “F” insulation system
- Automatic Overload protected
- Capacitors shipped loose on 1-phase designs
- 1.0 Service Factor
- Keyed shaft with 1/4-20 UNC tapped hole on end
- 34” long leads
- Motor venting protected against insects and rodents
- Double sealed ball bearings
NOTE: This motor is an air-over design and is intended for use in a fan or blower applications where the motor is mounted within the air stream of the fan or blower it is driving: The motor requires this air flow for cooling. Any other use will void the warranty, as the motor will overheat and fail prematurely.
Specifications
|
Application: |
Crop Dryer |
|
Output HP: |
5-7.0 |
|
Output KW: |
3.7 |
|
Output RPM: |
3450 |
|
Frame NEMA: |
182TZ |
|
Mount NEMA: |
Base Mount |
|
Enclosure NEMA: |
DPAO |
|
Enclosure IEC: |
IP22 |
|
Voltage: |
230 |
|
Frequency (Hz): |
60 |
