Replaces both red and yellow wing style connectors. Red with yellow skirt. Maximum operating temperature is 221 deg F. 600 V maximum. 22 AWG minimum wire gauge, 8 AWG maximum wire gauge. UL, CE, IEC and CSA agency approved.
Features
- Offers a strong bite in a pigtail application for a long-lasting connection
- An expandable spring lets you take in more wire uptake and reuse
- The R/Y+ is dual color-coded so this 1 connector replaces your traditional red and yellow connectors
- Great for all types of jobs – from industrial and residential construction, to automotive, marine and appliance applications
- Use with copper conductors ranging from 22 to 8 AWG
- Built with polypropylene and thermoplastic elastomer material
- Red/yellow connector is flame-retardant and operates in temperatures up to 221 deg F
- Use on building wire rated 600 V and on signs, fixtures or luminaires rated 1000 V
Additional Information
- Color: Red/Yellow
- Contact Material: Steel
- Height: 4.81 in
- Housing Material: Polypropylene/Thermoplastic Elastomer
- Mounting Type: Screw
- Voltage Rating: 600 V
- Width: 0.76 in
- Wire Size: 22 to 8 AWG
