WEG Single Phase General Purpose Cast Iron Motor is the perfect option for applications that require robustness, low weight, and high performance in a single product. These cast iron motors offer good thermal performance and easy installation and maintenance. Because of their high starting torque, they are particularly well suited for heavy starting loads.
Features:
- C-Face mounting provisions less base
- Ball bearings
- Class F insulation
- F1 mounted
- V-ring seals
- NPT Threaded holes in terminal box
- Cannot be modified with terminal box on the opposite side
- Drip cover NOT included
- Built-in conduit box located at 12:00
- Uses drip cover kit 175932.00
Specifications
|
Application: |
General Purpose |
|
Output HP: |
3 |
|
Output KW: |
2.2 |
|
Output RPM: |
1745 |
|
Frame NEMA: |
184TC |
|
Mount NEMA: |
C-Face No Base |
|
Enclosure NEMA: |
IC411 – TEFC |
|
Enclosure IEC: |
IP55 |
|
Voltage: |
208-230/460 |
|
Frequency (Hz): |
60 |
