APPLICATIONS: General purpose with continuous duty rating. Standard operating characteristics and mechanical construction for use under usual service conditions without restriction to a particular application or type. Not for outdoor use.
FEATURES:
- No overload protection
- Four in One design
- Capacitor Start Induction Run design
- Double sealed ball bearings, mechanically locked on shaft end
- Heavy gauge steel constructions
- Bolt-on, removable rigid base
- Suitable for horizontal or vertical mounting
- Rated 60/50 hertz
- 1.15 Service Factor
- Will accept brake kits
- Will accept drip cover kits
- UL Recognized and CSA Certified
- Footnotes: 68
Specifications
|
Application: |
General Purpose |
|
Output HP: |
0.75//0.50 |
|
Output KW: |
0.55//0.37 |
|
Output RPM: |
1725//1425 |
|
Frame NEMA: |
56C |
|
Mount NEMA: |
C-Face With Base |
|
Enclosure NEMA: |
TEFC |
|
Enclosure IEC: |
IP43 |
|
Voltage: |
115/208-230//110/220 |
|
Frequency (Hz): |
60//50 |
