LEESON Single Phase Stainless Steel Boat Hoist Motors provide customized features that are needed to support the Boat Hoist Industry.
FEATURES:
- Stainless Steel frame, base, capacitor case and conduit box cover
- 15 Minute Duty Cycle
- 5/8″ Keyed output shaft
- Drain Holes located at 6:00 position
- Die Cast Aluminum endbells
- Capacitor case located at 12:00
- 115/230 Volt – 1.15 Service Factor
- UL and CSA listed
Specifications
|
Application: |
Boat Lift Duty |
|
Output HP: |
3/4 |
|
Output KW: |
0.56 |
|
Output RPM: |
1725 |
|
Frame NEMA: |
56C |
|
Mount NEMA: |
C-Face With Base |
|
Enclosure NEMA: |
TENV |
|
Enclosure IEC: |
IP43 |
|
Voltage: |
115/230 |
|
Frequency (Hz): |
60 |
